The horizontal spindle design has excellent chip removal effect and improved processing efficiency.
The positioning accuracy is 0.01mm. The resolution of the transmission system is 0.001mm.
Automatic tool change, maximum support 6 tools. And equipped with high-precision tool measuring instrument
The design is more humane, with multiple safety protections
4.1 When the machine is running, the protective door cannot be opened.
4.2 The system startup requires a special key to start, which effectively protects the safety of the machine.
4.3 The machine has an automatic detection and alarm prompt function, effectively avoiding misoperation
5. The internal transmission structure of the machine adopts high-performance aviation aluminum casting technology, which has a longer precision maintenance life and stronger rigidity.
6. Professional medical equipment has beautiful design, exquisite structure, easy to carry, and can enter any dental technique center or clinic.
7. It is widely applicable. Wet and dry type, suitable for titanium, zirconium oxide, cobalt chromium, PMMA, wax and other materials.
|
Technical Parameters
|
|
X Axis working Size
|
130mm
|
|
Y Axis working Size
|
190mm
|
|
Z Axis working Size
|
56mm
|
|
A Axis working size
|
±180°
|
|
Speed of Spindle
|
6000-60000RPM
|
|
Power of Spindle
|
1200W
|
|
Quantiry of Tools tool magazine capacity
|
6
|
|
Power supply working voltage
|
220V
|
|
bleed pressure
|
0.6mpa
|
|
Method of Cutting
|
Dry cut/wet cut
|
|
Size
|
590x620x690mm
|
|
weight
|
130kgs
|
